Operation
Steering
199 / 564
If the U-turn steer was not activated, then the cause of it is shown on the R-
Touch:
– Unlock the main steering switch (44).
– Drive faster, the minimum speed (0.5 km/h) shouldn’t be reached.
– The speed is too high. Please continue reducing the speed.
ADVICE
Once the main steering switch is opened during the road driving, the speed is reduced
automatically for the safety reasons. If the key (9) on the joystick is pressed and held
in such a way at too high speed and with the main steering switch opened, at first the
speed is reduced automatically to the maximum activation speed, and then the func-
tion "U-turn steer in the operating mode Road" becomes active. Then the key (9) can
be released again.
In case you need to continue driving with high or maximum speed, please perform the
following actions:
– First level the rear axles (See Page 196).
– Synchronize articulation steering (See Page 197).
