Malfunction and Remedies
Swinging away the fuel tank
523 / 564
8.15 Swinging away the fuel tank
For better access to the bottom side of the hydraulic pumps in the engine compart-
ment, it is possible to swing away the fuel tank as follows:
– Screw out the holding bolt (1) left beside the tank fuel feed pipe.
– Slowly lower the tank by rotating the long threaded rod (2) right besides the rear
apron bracket.
