Operating Components
Ladders
61 / 564
5.1.2 Ladder bunker
(3) Rope bunker ladder
(4) Bunker ladder unlocking rope
Pull the unlocking rope (4) to release the ladder, pull the ladder down at the same time
with the pull rope (3).
Bunker ladder and platform are ready for ascend
(1) Bunker door lock
(2) Lower ladder part
Fold down the lower half of the ladder (2) until stop. When you open the bunker door,
the diesel engine shuts off automatically.
