Malfunction and Remedies
Relays list
489 / 564
8.3 Relays list
No. Designation Position in
the machine
Comments Item no.
K01 Relay main load pin
15
Central electrical
system in the dri-
ver's cabin
Load relay pin 15, 70 A 320009900
K03 Relay direction indica-
tor
Seat console Flasher unit 320002100
K06 Relay window wiper Central electrical
system in the dri-
ver's cabin
switches the wiper motor 320057300
K07 Relay central lubrica-
tion
Central electrical
system in the dri-
ver's cabin
switches the central lubricating
pump
320015400
K13 Relay lifter working
floodlights
Lifter fuse box switches E56/E57/E70/E71 320015400
K14 Relay scalper working
floodlights
Lifter fuse box switches E26/E27 320015400
K15 Relay lifter working
floodlights to outside
Lifter fuse box switches E28/E29 320015400
K19 Relay rotating bea-
cons
Central electrical
system in the dri-
ver's cabin
switches all rotating beacons 320015400
K43 Battery relay in front of battery
case
electrically operated battery main
switch
320076200
R600 EMS Volvo main relay Front on diesel
engine
Volvo part confirmed by
