Operation
Central lubricating system
344 / 564
ADVICE
In any case, make sure that there is always sufficient grease supply in the grease
reservoir. In no case may the grease supply be used up so that air enters the pipe
system!
ADVICE
Fill the 2 kg supply reservoir when the engine is warm from operation as the grease
bucket stands on a heated platform. In such a way refilling is possible with a minimum
effort.
6.23.1 Filling up grease gun
(1) Stopcock
(2) Nipple for filling up the hand
lever grease gun
Holder for grease gun
A stopcock (1) and a plug-in connector (2) for filling the hand lever grease gun is
located in the supply hose to the lubricating pump. It enables direct filling of the hand
lever grease gun in the on-board tool kit from the grease bucket. For this purpose,
press the hand lever grease gun into the connecting nipple (2) and close the stopcock.
When you press the pump lever of the grease bucket, then the hand lever grease gun
is filled up with lubricating grease.
