Operation
Lifter
284 / 564
6.14.20 Setting row distance for the RR-V lifter
DANGER
Hazard of very serious injury due to the machine starting.
– Shut off the engine before switching and secure it against inadvertent starting (pull
off the ignition key)!
The row distance for the RR-V lifting unit may be set to either 45 cm or 50 cm.
Switching is performed as follows:
– Raise the lifter.
– Switch off machine drive, switch off engine and secure it against inadvertent start-
ing (pull off the ignition key).
– Hang the securing chains onto the lifter.
– Remove coarse soiling in the area of the components to be shifted.
(1) Securing chain
