Malfunction and Remedies
Fuses
479 / 564
8.2.2 Electronic fuses
The fuses F70r - F307r are implemented as self-resetting electronic automatic cut-
outs. If the light emitting diode (LED) (1) of a fuse is lit, then the fuse is overloaded and
power supply to the connected component interrupted.
The self-resetting electronic fuses are
– in the seat console (See Page 481)
– in the central electrical system outside on the driver's cabin (See Page 484)
– in the lifter fuse box (See Page 485)
– in the engine fuse box (See Page 487)
Electronic fuses in the central electrical
system
