ROPA Tiger 6 - Setting the Leaf Sensor

Maintenance and Service
Defoliator
422 / 564
1
The three-point suspension cannot be lowered to the ground with the mini-joystick (1)
with the defoliator folded in maintenance position. It automatically stops lowering at a
safe height above the ground. It can only be lowered further by pressing and holding
the service key (24). This function protects the adjusting spindles and the rollers move-
ment.
24
ATTENTION
The lifter must not be lowered to the ground with the defoliator raised on the
rollers movement. This would bend the adjusting spindles of the rollers move-
ment.
The lifter must be lowered to the ground only on the lifting shares or the depth-
control roller.
7.8.2 Setting the leaf sensor
Before the start of each harvesting season, adjustment of the leaf sensor must be
checked as follows and, in case of need, readjusted:
Two people are required for this activity. One person moves the leaf sensor, the sec-
ond person reads the values determined on the R-Touch.
– Switch on ignition, but do not start the engine.
– Open expert mode on the R-Touch (See Page 124) and call up the display field
"Steering" (See Page 110).
Main menu
Bunker
Bunker auger delay (sec)
Unloading engine rpm pile
Unloading engine rpm lifting
Unloading stage 2 speed %
Start delay unloading stage 4
2
850
1300
50
1
The following values must be displayed:
Left Middle Right
approx. -9850 0 approx. 9850
