Operation
Chassis
220 / 564
6.11.3 Menu Chassis control on the R-Touch
The chassis of the machine can be driven to the different heights in the menu "Special
functions", submenu "Chassis control" (e.g. for cleaning of the machine). The chassis
control must be set, e.g. after cleaning, to "Active" again.
Hand steering articulation
Reverse ventilator drives
Programmable keys activation
B638 fuel pressure fine filter
DANGER
Danger of fatal injuries when raising and lowering the machine.
People, staying in the hazard zone of the machine, might be jammed or trapped.
– Always make sure that nobody stays in the hazard zone.
– Go around the machine to ensure that there are no people or objects in the hazard
zone.
ADVICE
During harvesting the chassis control must be always set to "Active"! So long as it is
not set to "Active", the driving speed is limited to 5 km/h.
6.11.3.1 Chassis control "Active"
The chassis control of the machine is "Active", the chassis cylinders of the rear axles
drive in the operating mode "Road" on average by 30% out.
In the operating mode "Field" the chassis cylinders drive on average by 50% out.
In case of leakage the system corrects the height during lifting automatically.
