ROPA Tiger 6 - Manual Inclination; Automatic Inclination (Option)

Operation
Chassis
222 / 564
6.11.4 Manual inclination
14
13
DANGER
Danger of fatal injuries during inclination of the machine.
– Make sure that there are no persons in the hazard zone when you perform
machine inclination!
(13) Manual inclination to the right:
As long as this key is held, the left chassis cylinders drive out and the right chassis
cylinders drive in.
(14) Manual inclination to the left:
As long as this key is held, the right chassis cylinders drive out and the left chassis
cylinders drive in.
ADVICE
The machine can be aligned vertically on the swing axles in the operating modes
"Field" and "Road" by simultaneously pressing and holding the keys (13) and (14).
Once the machine is aligned, the icon appears on the R-Touch.
6.11.5 Automatic inclination (option)
15
