ROPA Tiger 6 - Keypad II

Operating Components
Operating console R-Concept
81 / 564
5.6.5 Keypad II
(18) Offset-steer stage to the left: (See Page 203).
Key for gradually adjusting the offset-steer stage left.
(19) Offset-steer stage to the right: (See Page 203).
Key for gradually adjusting the offset-steer stage right.
(20) Lifter side shift left: (See Page 281).
(21) Lifter side shift right: (See Page 281).
(22) Shift row distance 45-50: (See Page 284).
Shifts share body, eccentric drives and scalper (only with variable lifter RR-V).
Lifting share cleaning function: (See Page 267).
(23) Shift depth-control roller 45-50: (See Page 284).
Shifts only depth-control wheels on the depth-control roller (only with variable lifter RR-
V).
(24) Service key:
E.g. required for activating of automatic folding.
(25) Activate/switch off additional axle: (not used at Tiger 6)
