Operating Components
Driver's cabin overview
62 / 564
5.2 Driver's cabin overview
2
1
3
4
(1) Roof console
(2) Roof console storage compartment
(3) Roller blind
(4) Video monitor
6
10
5
12
8
11
7
9
(5) Steering column
(6) Operating console at driver’s seat
(7) Bottle holder
(8) Central electrical system cover
(9) Rear driver's cabin wall storage compartment
(10) Emergency seat
(11) Cool box
(12) Operating panel bunker emptying
