Operating Components
Switches on roof console
89 / 564
5.8 Switches on roof console
(58) Radio with Bluetooth (see separate operating manual)
(59) Rotating switch to fold in/out the left rearview mirror
(60) Switch for rotating beacons
(61) Not used
(62) Not used
(63) Not used
(64) High beam control (above) / turn signal control (below)
(65) Switch parking/driving lights
(66) Switch flashing warning system
(67) Switch mirror heating
ADVICE
The mirror heating switches off to conserve battery life in few minutes with the stopped
diesel engine.
(68) Four-way switch for electrical adjustment of right and left outer mirrors.
(69) Rotating switch to fold in/out the right rearview mirror
(70) Outlet 12V/5A maximum
(71) Dummy cap, installation option for radio equipment, cable for voltage supply
located behind the dummy cap in the roof console
