Operation
Lifter
281 / 564
6.14.18 Lifting unit side shift manual
The complete defoliator and lifting unit may be shifted manually to the right or left
from the driver's seat. For this purpose, press the key "Side shift left" (5) or "Side shift
right" (6) on the keypad II.
6
5
Lifter side shift left:
As long as this key is pressed with the lifting unit raised, the lifting unit moves to the
left.
If the lifting unit is not shifted to the left stop, the LED in the key flashes.
The LED lights up as soon as the lifter side shift is at the left stop.
Lifter side shift right:
As long as this key is pressed with the lifting unit raised, the lifting unit moves to the
right.
If the lifting unit is not shifted to the right stop, the LED in the key flashes.
The LED lights up as soon as the lifter side shift is at the right stop.
ADVICE
If, while driving with raised lifting unit, the buttons "Lifter side shift right" (6) and "Lifter
side shift left" (5) are pressed simultaneously, then the lifting unit and the rollers move-
ment move to the central position. Both LEDs are lit.
