Operation
Infeed conveyor
292 / 564
6.15.2 Infeed conveyor reverse
If the infeed conveyor is blocked by a foreign object, this is shown on the R-Touch with
the warning symbol. A warning tone sounds at the same time. The lifter drive and main
drive then stop automatically.
ATTENTION
Repeated reversing of a blocked infeed conveyor leads to damage to the belt
(sometimes even to the belt being ripped off).
There are no guarantee or warranty claims for such damage!
– In case of blockages, the reversing device may only be used very carefully.
The operating direction of the infeed conveyor may be reversed by pressing the key
(32) "Reverse infeed conveyor" on the keypad III.
This offers a possibility of more easily loosening the dirt, which may collect between
the upper and the lower conveyor in case of very sticky ground, and therefore being
better able to remove it. For this purpose, with lifter raised and conveyor run empty,
press the reversing key (32) several times.
