Operation
Infeed conveyor
293 / 564
6.15.3 Ground operation infeed conveyor
The infeed conveyor belt can also be run forwards or backwards using the ground
operation.
Ground operation on the left side of the machine
These keys are ONLY active, when no one is sitting in the driver‘s seat. In addition,
the vehicle must be in lifting mode.
It means:
Bunker is swung out.
Operating mode "Field" is switched on.
ADVICE
As soon as a switch ground operation is pressed, the reversing buzzer sounds to warn
bystanders.
When this key is pressed, the infeed conveyor runs and the 1st, 2nd and 3rd strainer
wheels rotate. In addition, the elevator and the auger run for as long as the key is
pressed. If this key is pressed twice in brief succession and then held down, this drive
is reversed.
