Operation
Lifter
282 / 564
6.14.19 Lifting unit side shift automatic
Side shift of the lifter is performed automatically, if the following conditions are fulfilled:
Operating mode "Field".
drive pedal of the machine is pressed.
Lifting unit is raised.
The offset-steer direction, opposite to the last active offset-steer, is preselected.
The shifting process begins as soon as the counteractive offset-steer has been prese-
lected.
Example:
The conditions stated above are fulfilled. Offset-steer left was active. The lifter is side
shifted to the right. Now, U-turn steer is activated. The lifter remains in its position.
Then, offset-steer 2 right is preselected. In this moment, the lifter is side-shifted to the
left.
In specific situations, for instance when starting to lift a field, this function is not
desired.
Switch off automatic side shift temporarily:
– If offset-steer "left 0" and offset-steer "right 0" are preset (lifting-through steer), the
automatic side shift is switched off.(See Page 201)
.
Switch off automatic side shift permanently:
– Select the option "MANUAL“ instead of the option "AUTO" in the menu “Main set-
tings", submenu "Attachment", line "Lifter side shift".
additional topper lifting
lifter up + multifunction
single-row automatic stage
attachment (lifter/defoliator)
