Operation
Road traffic
185 / 564
6.8.2.1.2 Actuate chain hoists in coupling mode
– Raise the three-point suspension to the stop.
– Press the key on keypad III twice to activate "chain hoists coupling mode".
ADVICE
In the "chain hoists coupling mode" the chain hoists are controlled with the joystick (1)
exactly as the three-point suspension in the "three-point suspension coupling mode".
The coupling mode icon is shown on the R-Touch.
– After a short wait time the R-Touch shows the "chain hoists coupling mode" selec-
tion window.
– Touch the "road mode" field (8).
The machine executes the following movement in succession:
– The scalping height adjustment set the scalper bracing tube to the top position
– The roller height adjustment sets the depth-control roller right and left to the top
position
– The share-depth adjustment sets all share bodies to the top position
