Operation
Road traffic
186 / 564
– Move the lifting unit centrally over the additional chassis. The two chain hoists can
be lowered with the mini-joystick (1) for a better view.
– Set parking brake. Leave diesel engine running.
– Exit the machine. If the chain hoists are not yet lowered or not lowered far enough,
they can be lowered with the ground operation. Press and hold the deadman
switch (12). Lower the chain hoist on the left and right with the keys (3) and (5).
– Attach the hook on the right and left chain hoist to the eyelet (9) on the additional
chassis.
