Operation
Road traffic
187 / 564
– Press and hold the deadman switch (12). Lift the additional chassis with the keys
(2) and (4).
4
2
12
– Lift the additional chassis until the safety hooks (6) and (7) lock, as shown in the
pictures.
6
10
7
– Lock them by lowering the unlocking step (10).
10
– Press the key . The coupling mode is terminated, the icon and the LED in
the key disappears.
– Close the "chain hoists coupling mode" selection window on the R-Touch.
