Operation
Bunker
321 / 564
6.18.7 Folding the machine manually out/in
If the automatic folding does not work due to some technical malfunctions, you can
fold the bunker "manually", step by step in operating or transport position.
WARNING
Hazard of extremely severe injuries.
– Make sure, that nobody stands in the hazard zones when the machine is started.
For folding out perform the following actions consecutively:
1. Fold elevator, all side and rear bunker grids out. (See Page 309)
2. Fold bunker bars and the front bunker wall out. (See Page 313)
