ROPA Tiger 6 - Functional Area R-Direct; HOME Key

Operation
R-Concept
112 / 564
6.3.2 Functional area R-Direct
5
7
9
8
5a
6
R-Direct operating panel
The R-Direct (5) (YELLOW colour of screen and operating panel) allows the driver to
access the main menu, order management and warning thresholds adjustment.
The display fields can be switched the same way and by pressing the HOME you can
return to the main screen.
6.3.2.1 HOME key
The key HOME (8) is always available on the R-Touch as well as on the R-Direct oper-
ating panel. Pressing once the key HOME you return again to the main screen.
8
