5.6.9 Joystick with multi-functional handle
The joystick enables easy control of a multitude of functions of the machine with a
single hand without distracting the attention of the operator. For better orientation, a
transparent sticker is located on the side window of the driver's cabin containing the
following schematic overview of all functions of the joystick with multifunctional handle.
You may find a comprehensive description in the chapter "Joystick" (See Page 147).
9
6
5
4
1
7
8
10
2
3
11
12
13
14
