Operating Components
Operating console R-Concept
86 / 564
Joystick movements
Press joystick for-
ward
= Increase speed of driving power/cruise con-
trol. ONLY in operating mode "Field".
Pull joystick back-
ward
= Reduce speed of the traction drive/cruise con-
trol. ONLY in operating mode "Field" (See
Page 174).
Pull joystick to the
left
= Rear axles steer to the left (See Page 207).
Push joystick to the
right
= Rear axles steer to the right (See
Page 207).
