Operation
Chassis
223 / 564
(15) Automatic inclination off/on:
If this key is pressed in the operating mode "Field", the automatic inclination system is
ON (LED lights). The machine automatically inclines on the axles horizontally. Maxi-
mally the chassis can be inclined on the axles by 10 % to the right or left. If you press
this key again, the automatic inclination system is OFF (LED doesn't light). The LED
does not light.
In the operating mode "Road" the inclination system turns OFF automatically. The
machine aligns itself vertically on the axles. The machine is lowered over the rear
axles on transporting height of 400 cm (30%). Once the machine is aligned, the icon
appears on the R-Touch.
