Malfunction and Remedies
Fuses
488 / 564
No. Ampere Function
F79r 100 mA
B84 traction drive backwards
B107 pressure air tank
24 V
F123r 100 mA B156/B157 declination sensor articulation rear part 24 V
F125r 100 mA
B150 level axle 3 right
B151 level axle 3 left
24 V
F126r 100 mA
B148 level axle 2 right
B149 level axle 2 left
24 V
F127r 100 mA
B80 PS emergency steering pump
B177 drive pump turning angle
24 V
F90r 100 mA
B75 sensor guide grid 1st turbine
B51 PDG greasing
8.5 V
F91r 100 mA
B10 sensor guide grid 2nd turbine
B35 sensor unloading conveyor articulation 1
8.5 V
F92r 100 mA
B21 rpm turbine 1
B22 rpm turbine 2
8.5 V
F93r 100 mA
B23 rpm turbine 3
B34 sensor unloading conveyor height
8.5 V
F94r 100 mA
B120 unload conveyor articulation 2
B166 greasing CVR traction drive
8.5 V
F95r 100 mA B121 sensor guide grid 3rd turbine 8.5 V
F96r 100 mA
B118 cross conveyors rpm
B119 rpm longitudinal conveyors
8.5 V
F97r 100 mA
B163 height elevator
B164 height bunker bar rear
8.5 V
F98r 100 mA
B161 height bunker auger front
B162 height bunker auger rear
8.5 V
F99r 100 mA B165 height bunker bar front 8.5 V
