Operation
Defoliator
236 / 564
Defoliator pressure relief left
Defoliator pressure relief right
Choose this function with R-Select. The defoliator relief pressure is set in steps of
5 bar each. The lower threshold is at about 30 bar.
- Key = reduce set pressure
+ Key = increase set pressure
If the relief pressure is to be totally reduced, then the desired pressure should be first
set to 30 bar. If the key - is pressed and held for several seconds after reaching this
value, then the relief pressure is lowered to 0 bar.
The following reference values are used to set the defoliator pressure relief: for RBS
and RAS 40-60 bar, for RIS 50-80 bar and for RES 45-65 bar.
The relief pressure must be set during lifting in the field when the defoliator is in the
correct operating position.
When the defoliator relief pressure must be readjusted, the display of the defoliator
relief pressure on the R-Touch is highlighted orange.
