Operation
Elevator
310 / 564
(1) Support cylinders
For lifting, the elevator must generally be folded out to the stop. The elevator is then
affixed in the top position by the two support cylinders (1). The two support cylinders
are fed by the elevator drive and always extended to the stop after switching on the
drive.
ATTENTION
Only fold the elevator out/in if there are no longer any beets in the elevator. If the ele-
vator is blocked or if for any other reason there are still beets in the elevator and it
is raised anyway, then this causes severe damage to the elevator rocker arm. Such
damage is assumed as negligently caused and covered neither by warranty nor by
accommodation.
