Maintenance and Service
Defoliator
420 / 564
Before lifting the defoliator up, the side-shift moves the lifting unit to the centre position
(to prevent damage to the spherical bearing on the maintenance position cylinder).
As an alternative to R-Select, the lifting unit can be operated from the ground. Press
the defoliator maintenance position key (6) and then the deadman switch (1).
In order to move the lifting share or scalper to the right height without climbing up and
down to the cabin, the diesel engine can be started and stopped with the keys (8 and
9) (See Page 158) and the three-point suspension can be raised and lowered.
ATTENTION
The lifter must not be lowered to the ground with the defoliator raised on the
rollers movement. This would bend the adjusting spindles of the rollers move-
ment.
