Malfunction and Remedies
Fuses
483 / 564
No. Ampere Function
F24 7.5 Parking light right front, left rear
F25 7.5 Parking light left front, right rear, switch lighting.
F26 7.5 Dimmed headlight
F27 7.5 Headlight
from
light
F28 20
Pin 30 A36 I/O module III (PR2H lifter only)
Pin 30 A38 I/O module III (RR lifter only)
F29 not used
F30 15 Pin 30 A34 I/O module I
F31 15 Pin 30 A34 I/O module I
F32
--
15
not used (PR2h lifter only)
ASW lifter (relay K13,K14,K15), RR lifter only
from
X2
F33 7.5 Voltage transformer 2 (cool box outlet) Pin 15
F34 10 Hazard warning system
F35 15 Rotating beacons relay K19
F36 15 24 V outlet seat console
F37 15
Mirror adjustment, internal lights, voltage transformer 1 (radio
outlets)
from
X2
F38 7.5 12V outlets roof console, radio
F39 5 12 V seat console
12 V voltage
transformer 1
F40 3 A45 telematics computer Pin 30 battery
F41 7.5 12 V cool box, Accosat (option)
12 V voltage
transformer 2
