Malfunction and Remedies
Fuses
486 / 564
No. Ampere Function
F113r 100 mA
B189 sensor share bodies steering 1
B190 sensor share bodies steering 2
8.5 V
F114r 100 mA
B191 sensor share bodies steering 3
B192 sensor share bodies steering 4
8.5 V
F301r 100 mA
B68 DS sensor defoliator relief right
B69 DS sensor defoliator relief left
24 V
F302r 100 mA
B70 PS stone protection
B28 rpm defoliator
24 V
F303r 100 mA
B160 rpm rubber-defoliator shaft, only RES
B203 sensor pos. rollers movement sideways
24 V
F304r 100 mA
B193 sensor lifting depth row 1
B194 sensor lifting depth row 2
24 V
F305r 100 mA
B195 sensor lifting depth row 3
B196 sensor lifting depth row 4
24 V
F306r 100 mA
B197 sensor lifting depth row 5
B198 sensor lifting depth row 6
24 V
F307r 100 mA
B204 DS last lifting roller
B112 DS front lifting rollers
24 V
ROPA sticker item no. 3550601GB
