Lubrication schedule for RR 6-row lifter
536 / 564
Lubricating point Number of
nipples
Every
oper. hrs.
Machine
Knuckle joints of the steering knuckles of the portal axle 4 200
Knuckle joints of the steering knuckles of the rear axles 8 200
Ball bearing activation shaft brake valve 2 500
Upper lever artic. rotation point middle (only with option
additional chassis preparation)
1 500
Universal joint of cardan shafts:
Cardan shafts of the front axle to cardan intermediate
shaft
4 200
Cardan intermediate bearing rigid (over strainer wheel 1)** 1 500
Cardan shaft from intermediate cardan bearing to rear 2 200
Intermediate cardan shaft to front reduction gears 1 200
Cardan shaft from reduction gears to CVR gearbox 2 200
Cardan shaft from reduction gears to 3rd axle 2 200
* Grease with copper paste!
** 3 strokes of the grease gun
ADVICE
All lubricating points must also be lubricated after each washing of the machine. After
washing of the machine, the central lubrication system must also be lubricated using
at least 2 intermediate lubrication cycles.
Grease ROPA item no. 435006200
as per DIN 51825, NLGI-class 2, type: KP2K-20,
at low outdoor temperatures KP2K-30.
No lubricating greases containing solid lubricants may be employed. Biologically
degradable greases are also admissible.
