Operating Components
Operating console R-Concept
78 / 564
The following functions are included in R-Select mode:
Service position defoliator Fold leaf sensor
Elevator rpm Defoliator pressure relief left
Defoliator flap up/down (only
with RAS)
Defoliator pressure relief right
Leaf-spreader rpm (not with RIS) Pressure stone protection
Rpm defoliator shaft Leaf-spreader fold/unfold (not
with RIS + RES)
Scalper height (not with RES) Elevator fold/unfold
Cleaning shaft rpm (only with
RES)
Bunker bar + bunker front wall
folding
Cleaning shaft height (only with
RES)
Articulate unload conveyor
Shaking share rotational speed Bunker auger front and rear up/
down
Rpm depth-control shaft Bunker auger only front up/down
Lifting rollers rpm Bunker auger only rear up/down
Rpm infeed conveyor Set temperature air conditioning
in Celsius or Fahrenheit
Rpm strainer wheels Fan rotational speed
Guide grids height
