Operating Components
Switch ground operation over front wheels
93 / 564
When this key (83) is pressed, then the 2nd and 3rd strainer wheels rotate. In addition,
the elevator and the auger run for as long as the key is pressed.
When this key (84) is pressed, then the 1st, 2nd and 3rd strainer wheels rotate. In
addition, the elevator and the auger run for as long as the key is pressed.
* When this key (85) is pressed, then the infeed conveyor runs. In addition, the 1st,
2nd and 3rd strainer wheels rotate. In addition, the elevator and the auger run for as
long as the key is pressed.
* When the key (86) is pressed, then the defoliator shaft, if existing, leaf auger con-
veyor and leaf-spreader, depth-control shaft, all lifting rollers, infeed conveyor and 1st,
2nd and 3rd strainer wheels rotate. In addition, the elevator and the auger run for as
long as the key is pressed.
*) If this key pressed twice in brief succession and then held down, only this drive is
reversed.
