VLAN configuration mismatch on non-DHCP/NAT WLAN
TABLE 455 VLAN configuration mismatch on non-DHCP/NAT WLAN event
Event VLAN configuration mismatch detected between configured and resolved VLAN
with DVLAN/VLAN pooling configuration on non-DHCP/NAT WLAN.
Event Type apCfgNonDhcpNatWlanVlanConfigMismatch
Event Code 1024
Severity Critical
Attribute "ssid"="xxxx", "configuredVlan"="5", "vlanId"="11", "apMac"="xx:xx:xx:xx:xx:xx"
Displayed on the web
interface
DHCP/NAT gateway AP [{apMac}] detected VLAN configuration mismatch on
non-DHCP/NAT WLAN [{ssid}]. Configured VLAN is [{configuredVlan}] and
resolved VLAN is [{vlanId}]. Clients may not be able to get IP or access Internet.
Description This event occurs when the AP detects a non DHCP/NAT WLAN. VLAN
configuration mismatches with DVLAN/VLAN pooling configuration on gateway
AP.
VLAN configuration mismatch on DHCP/NAT WLAN
TABLE 456 VLAN configuration mismatch on DHCP/NAT WLAN event
Event VLAN configuration mismatch detected between configured and resolved VLAN
with DVLAN/VLAN pooling configuration on DHCP/NAT WLAN
Event Type apCfgDhcpNatWlanVlanConfigMismatch
Event Code 1025
Severity Critical
Attribute "ssid"="xxxx", "vlanID"="xxxx",
"configuredVlan"="5","vlanId"="11","apMac"="xx:xx:xx:xx:xx:xx"
Displayed on the web
interface
DHCP/NAT gateway AP [apMac}] detected VLAN configuration mismatch on
DHCP/NAT WLAN [{ssid}]. Configured VLAN is [{configuredVlan}] and resolved
VLAN is [{vlanId}]. Clients may not be able to get IP or access Internet.
Description This event occurs when the AP detects a DHCP/NAT WLAN. VLAN configuration
mismatches with DVLAN/VLAN pooling configuration on gateway AP.
NOTE
Refer to Configuration Alarms on page 87.
Data Plane Events
NOTE
Events 530, 532, 537, 538, 550, 551, 552 and 553 are not applicable for SCG.
Following are the events related to data plane.
Event
Event Event
Data plane discovered on page 244 Data plane discovery failed on page 244 Data plane configuration updated on page 245
Data plane configuration update failed on page
245
Data plane rebooted on page 245 Data plane heartbeat lost on page 245
Events Types
Data Plane Events
Ruckus SmartCell Gateway 200 Virtual SmartZone High Scale and SmartZone 300 Alarm and Event Reference Guide
Part Number: 800-71565-001 Rev A 243

Ruckus Wireless Virtual SmartZone High Scale Specifications

General

Category	Gateway
Maximum Sites	10, 000
Virtualization Support	Yes
High Availability	Yes
Scalability	High
Supported Hypervisors	VMware ESXi, KVM
Management Interface	CLI, REST API
Security Features	Rogue AP detection
Supported Protocols	DHCP, SNMP, RADIUS

Summary

AP Communication Alarms

AP rejected

Triggers when an AP is rejected by the controller, often due to license limits.

AP configuration update failed

Indicates failure to update AP configuration details.

AP swap model mismatched

Occurs when AP model differs from the swapped configuration model.

AP LBS Alarms

AP failed to connect to LS

Occurs when AP fails to connect to the location based service.

AP State Change Alarms

AP rebooted by system

Indicates the AP has been rebooted by the system.

AP disconnected

Triggers when the AP disconnects from the controller.

AP deleted

Occurs when the AP is deleted on the server side.

Authentication Alarms

Authentication server not reachable

Indicates authentication fails as primary/secondary servers are unreachable.

Authentication failed over to secondary

Occurs when secondary RADIUS server is available after primary fails.

Authentication fallback to primary

Triggers when fallback to primary server occurs after secondary is used.

Control and Data Plane Interface Alarms

GtpManager (DP) disconnected

Indicates loss of TCP connection or failure to complete configuration.

Cluster Alarms

New node failed to join

Triggers when a node fails to join a cluster session.

Node removal failed

Occurs when a node cannot be removed from the cluster.

Node out of service

Indicates a node in the cluster is out of service.

Configuration Alarms

Zone configuration preparation failed

Occurs when controller fails to prepare zone configuration for AP.

AP configuration generation failed

Triggers when controller fails to generate AP configuration for a zone.

End-of-life AP model detected

Detects usage of end-of-life AP models during configuration generation.

Data Plane Alarms

Data plane configuration update failed

Indicates failure in transferring configuration updates to the data plane.

Data plane disconnected

Occurs when data plane disconnects from the controller.

Data plane physical interface down

Triggers when the physical interface link of the data plane is down.

System Events

No LS responses

Indicates controller got no response from Location Service (LS).

LS authentication failure

Triggers due to authentication failure connecting to Location Service.
