TABLE 41 Fails to establish TLS tunnel with AD/LDAP alarm (continued)
Alarm Fails to establish TLS tunnel with AD/LDAP
Displayed on the web
interface
[{srcProcess}] Fails to authenticate AD NPS[{authSrvrIp}] on SCG[{SCGMgmtIp}]
for User[{userName}
Description This alarm is triggered when TLS connection between the controller and AD/
LDAP fails.
NOTE
Refer to Authentication Events on page 189.
Control and Data Plane Interface Alarms
NOTE
This section is not applicable for vSZ-H.
Following alarm is related to control and data plane.
• GtpManager (DP) disconnected on page 77
GtpManager (DP) disconnected
TABLE 42 GtpManager (DP) disconnected alarm
Alarm GtpManager (DP) disconnected
Alarm Type lostCnxnToDblade
Alarm Code 1202
Severity Major
Aggregation Policy From the event code 1202 an alarm is raised for every event. A single event
triggers a single alarm.
Auto Clearance The alarm code is auto cleared with the event code 1201.
Attribute “ctrlBladeMac”=”aa:bb:cc:dd:ee:ff”, “srcProcess”=”aut”,
“realm”=”NA”, “ctrlBladeIp”=”1.1.1.1”, "dataBladeIp"="3.3.3.3",
"SCGMgmtIp"="2.2.2.2
Displayed on the web
interface
The connectivity between Control plane [{ctrlBladeIp}] and Data plane
[{dataBladeIp}] is lost at {produce.short.name} [{SCGMgmtIp}]
Description This alarm is triggered due to transmission control protocol (TCP) connection loss
or when control plane is unable to complete the configuration procedure
successfully.
Recommended Actions A manual intervention is required. Refer to Control and Data Plane Interface on
page 200 event 1201.
NOTE
Refer to Control and Data Plane Interface on page 200.
