TABLE 25 LS authentication failure alarm (continued)
Alarm LS authentication failure
Severity Major
Aggregation Policy From the event code 702 an alarm is raised for every event. A single event
triggers a single alarm.
Attribute “apMac”=“xx:xx:xx:xx:xx:xx“, “url”=““,”port”=““
Displayed on the
SmartZone web interface
AP [{apName&&apMac}] LBS authentication failed: url=[{url}], port=[{port}]
Description This alarm is triggered due to the authentication failure on connecting to the
location based service.
Recommended Actions The password needs to be corrected in the LBS service page.
AP failed to connect to LS
TABLE 26 AP failed to connect to LS alarm
Alarm AP failed to connect to LS
Alarm Type apLBSConnectFailed
Alarm Code 704
Severity Major
Aggregation Policy From the event code 704 an alarm is raised for every event. A single event
triggers a single alarm.
Auto Clearance The alarm is auto cleared with the event code 703.
Attribute “apMac”=“xx:xx:xx:xx:xx:xx“, “url”=““,”port”=““
Displayed on the
SmartZone web interface
AP [{apName&&apMac}] connection failed to LS: url=[{url}], port=[{port}]
Description This alarm is triggered when the AP fails to connect to the location based service.
Recommended Actions This alarm is triggered either when the location server is unreachable or the
network connection is unstable or the Domain Named System (DNS)
configuration is incorrect. It is recommended to check all the three possible error
codes - 701, 702 and 704.
NOTE
Refer to AP LBS Events on page 162.
AP State Change Alarms
Following are the alarms related to access point state changes.
• AP rebooted by system on page 70
• AP disconnected on page 70
• AP deleted on page 70
• AP cable modem interface down on page 71
• AP DHCP service failure on page 71
• AP NAT failure on page 72
Alarm Types
AP State Change Alarms
Ruckus SmartCell Gateway 200 Virtual SmartZone High Scale and SmartZone 300 Alarm and Event Reference Guide
Part Number: 800-71565-001 Rev A 69
