TABLE 240 MAP downlink connected event (continued)
Event MAP downlink connected
Attribute "mapMac="xx:xx:xx:xx:xx:xx"
Displayed on the web
interface
MAP [{apName&&apMac}] downlink connected
Description This event occurs when MAP downlink connects to the AP.
MAP downlink connected to EMAP
TABLE 241 MAP downlink connected to EMAP event
Event MAP downlink connected to EMAP
Event Type mapDlinkConnectWitheMap
Event Code 413
Severity Informational
Attribute "mapMac"="xx:xx:xx:xx:xx:xx", "emapMac="xx:xx:xx:xx:xx:xx"
Displayed on the web
interface
MAP [{apName&&apMac}] accepted connection from eMAP
[{emapName&&emapMac}]
Description This event occurs when MAP accepts the connection from Ethernet Mesh AP.
MAP downlink disconnected from EMAP
TABLE 242 MAP downlink disconnected from EMAP event
Event MAP downlink disconnected from EMAP
Event Type mapDlinkDisconnectWitheMap
Event Code 414
Severity Informational
Attribute "mapMac"="xx:xx:xx:xx:xx:xx", "emapMac="xx:xx:xx:xx:xx:xx"
Displayed on the web
interface
eMAP [{emapName&&emapMac}] disconnected from MAP [{apName&&apMac}]
Description This event occurs when Ethernet Mesh AP disconnects from MAP.
RAP downlink connected to MAP
TABLE 243 RAP downlink connected to MAP event
Event RAP downlink connected to MAP
Event Type rapDlinkConnectWithMap
Event Code 416
Severity Informational
Attribute "rapMac"="xx:xx:xx:xx:xx:xx", "mapMac="xx:xx:xx:xx:xx:xx"
Displayed on the web
interface
RAP [{apName&&apMac}] accepted connection from MAP
[{mapName&&mapMac}]
Description This event occurs when the root access point (RAP) accepts MAP connection.
Events Types
AP Mesh Events
Ruckus SmartCell Gateway 200 Virtual SmartZone High Scale and SmartZone 300 Alarm and Event Reference Guide
168 Part Number: 800-71565-001 Rev A
