Ruckus Wireless Virtual SmartZone High Scale User Manual

TABLE 693 Disk threshold back to normal event (continued)
Event Disk threshold back to normal
Severity Informational
Attribute “nodeName”=”xxx”,“nodeMac”=”xx:xx:xx:xx:xx:xx”, “perc”=”XX”
Displayed on the web
interface
Disk threshold [{perc}%] got back to normal on control plane [{nodeName}-C].
Description This event occurs when the disk usage comes back to normal.
License threshold exceeded
TABLE 694 License threshold exceeded event
Event License threshold exceeded
Event Type licenseThresholdExceeded
Event Code 960
Severity Critical 90%; Major 80%; Informational 70%;
Attribute "perc"="xxx", "nodeName"="", "nodeMac"="xx:xx:xx:xx:xx:xx",
licenseType="SG00"
Displayed on the web
interface
[{licenseType}] limit reached at [{perc}%]
Description This event occurs when the number of user equipment is attached to the system
has exceeded the license limit.
Rate limit threshold surpassed
TABLE 695 Rate limit threshold surpassed event
Event Rate limit threshold surpassed
Event Type rateLimitThresholdSurpassed
Event Code 1300
Severity Major
Attribute "mvnoId"=12 "wlanId"=1,"zoneId"="10" "ctrlBladeMac"="aa:bb:cc:dd:ee:ff"
"srcProcess"="radiusd" "UserName"=abc@xyz.com "realm"="wlan.3gppnetwor"
"SCGMgmtIp"="2.2.2.2" "aaaSrvrIp"="1.1.1.1" "AAAServerType"="Auth/Acct"
"ueMacAddr"="aa:bb:cc:gg:hh:ii" "MOR"=1000,"THRESHOLD"="500"
"TOR"="501"
Displayed on the web
interface
Threshold surpassed for AAA Server [{aaaSrvrIp}] and ServerType
[{AAAServerType}]
Description This event occurs when the rate limit threshold is surpassed. The threshold limit
for this event is dependent on the maximum outstanding request (MOR) value as
configured in the web interface of Authentication or Accounting Service. For
example, if the MOR value is 1000, and threshold limit is set to 70%, then this
event will be raised when total outstanding requests for this server exceeds the
limit of 701.
Events Types
Threshold Events
Ruckus SmartCell Gateway 200 Virtual SmartZone High Scale and SmartZone 300 Alarm and Event Reference Guide
Part Number: 800-71565-001 Rev A 329
