TABLE 232 AP received passive calibration request event (continued)
Event AP received passive calibration request
Displayed on the web
interface
AP [{apName&&apMac}] received Passive Calibration Request:
interval=[{interval}s], duration=[{duration}m], band=[{band}]
Description This event occurs when the AP receives the passive calibration request.
AP received passive footfall request
TABLE 233 AP received passive footfall request event
Event AP received passive footfall request
Event Type apLBSRcvdPassiveFFReq
Event Code 708
Severity Informational
Attribute “apMac”=”xx:xx:xx:xx:xx:xx”, “venue”=””, “interval”=””, “duration, =””, “band”=””
Displayed on the web
interface
AP [{apName&&apMac}] received Passive Footfall Request: interval=[{interval}s],
duration=[{duration}m], band=[{band}]
Description This event occurs when the AP receives the passive footfall request.
AP received unrecognized request
TABLE 234 AP received unrecognized request event
Event AP received unrecognized request
Event Type apLBSRcvdUnrecognizedRequest
Event Code 709
Severity Warning
Attribute “apMac”=”xx:xx:xx:xx:xx:xx”, “type”=””, “length”=””, "SCGMgmtIp"=""
Displayed on the web
interface
AP [{apName&&apMac}] received Unrecognized Request: type = [{type}], length =
[{length}]
Description This event occurs when the AP receives an unrecognized request.
NOTE
Refer to AP LBS Alarms on page 68.
AP Mesh Events
Following are the events related to access point (AP) mesh.
• EMAP downlink connected to MAP on page 166
• EMAP downlink disconnected from MAP on page 166
• EMAP uplink connected to MAP on page 167
• EMAP uplink disconnected from MAP on page 167
• MAP disconnected on page 167
• MAP downlink connected on page 167
• MAP downlink connected to EMAP on page 168
Events Types
AP Mesh Events
Ruckus SmartCell Gateway 200 Virtual SmartZone High Scale and SmartZone 300 Alarm and Event Reference Guide
Part Number: 800-71565-001 Rev A 165
