Date Code 20171006 Instruction Manual SEL-400 Series Relays
Instruction Manual
SECTION 2
PC Software
This section provides information on the following topics:
➤ QuickSet Setup on page 2.1
➤ Settings Database Management and Drivers on page 2.4
➤ QuickSet Main Menu on page 2.8
➤ Create and Manage Relay Settings on page 2.9
➤ QuickSet HMI on page 2.19
➤ Analyze Events on page 2.22
➤ QuickSet Help on page 2.32
SEL-400 series relays come with
ACSELERATOR QuickSet SEL-5030 Software,
a powerful relay settings, analysis, and measurement tool, to aid you in applying
and using the relay. QuickSet reduces engineering costs for relay settings, logic
programming, and system analysis. QuickSet makes it easier for you to do the
following:
➤ Create and manage relay settings
➢ Create settings for one or more relays
➢ Store and retrieve settings with Windows-based PCs
➢ Upload and download relay settings files to and from relays
➤ Analyze events
➢ Use the integrated waveform (single event reports) analysis tools
➤ Control the relay
➢ Command relay operation through use of a GUI environment
➢ Execute relay serial port commands in terminal mode
➤ Configure the serial port and passwords
SEL provides QuickSet for easier, more efficient configuration of the relay set-
tings. However, you do not have to use QuickSet to configure a relay; you can use
an ASCII terminal or a computer running terminal emulation software to access
all relay settings and metering. QuickSet gives you the advantages of rules-based
settings checks, SEL
OGIC control equation Expression Builder, and event analysis.
QuickSet Setup
Obtaining QuickSet
QuickSet can be obtained from the Download area of the SEL website. To have
the software automatically update as new relay drivers are released, download
and install SEL Compass Software, and then use Compass to download and
install QuickSet. When you download QuickSet within Compass, you will be
asked to select which relay drivers you wish to include. Select drivers for all SEL
