3.38
SEL-400 Series Relays Instruction Manual Date Code 20171006
Basic Relay Operations
Examining Metering Quantities
Step 7. Turn the relay on.
Step 8. View metering.
a. Type ACC <Enter> to log in to the relay at Access Level 1.
b. Type the password and press <Enter>.
c. Type MET <Enter>.
The relay displays the fundamental frequency (50 Hz or 60 Hz)
metering information in a manner similar to that shown in Figure 3.29.
The metering quantities of View Metering Using the Terminal on page 3.35 are
the fundamental line quantities. Other variants of the MET command give differ-
ent relay metering quantities. See Section 8: Metering, Monitoring, and Report-
ing of the product-specific instruction manual for more information on the
specific metering options available in a specific relay.
View Metering Using QuickSet
Use the procedures in the following steps to examine the relay metering with the
QuickSet HMI.
This example assumes that you have successfully established communication
with the relay (see Making an EIA-232 Serial Port Connection on page 3.4). In
addition, you must be familiar with relay access levels and passwords (see
Changing the Default Passwords in the Terminal on page 3.10 to change the
default access level passwords). You should also be familiar with QuickSet (see
Checking Relay Status in QuickSet on page 3.12 and Section 2: PC Software).
Step 1. Start QuickSet and establish a connection with the relay. See Step 1
and Step 2 of Checking Relay Status in QuickSet on page 3.12 for
details on how to do this.
Step 2. Set the relay to a nominal operation mode. Perform the initial Global
settings relay setup of Making Initial Global Settings in QuickSet on
page 3.28 to set the relay for 60-Hz operation, ABC phase rotation.
=>>MET <Enter>
Relay 1 Date: 02/26/2015 Time: 01:35:05.221
Station A Serial Number: 0000000000
Phase Currents
IA IB IC
I MAG (A) 398.882 399.041 398.784
I ANG (DEG) -1.18 -120.97 119.21
Phase Voltages Phase-Phase Voltages
VA VB VC VAB VBC VCA
V MAG (kV) 133.994 133.986 133.953 231.903 231.815 232.450
V ANG (DEG) -0.17 -120.02 120.18 29.91 -89.92 150.01
Sequence Currents (A) Sequence Voltages (kV)
I1 3I2 3I0 V1 3V2 3V0
MAG 398.901 2.159 2.588 133.977 0.692 0.713
ANG (DEG) -0.98 -62.68 -115.80 0.00 -53.25 -120.79
A B C 3P
P (MW) 53.44 53.46 53.41 160.31
Q (MVAR) 0.95 0.89 0.91 2.75
S (MVA) 53.45 53.47 53.42 160.33
POWER FACTOR 1.00 1.00 1.00 1.00
LAG LAG LAG LAG
FREQ (Hz) 60.00 VDC1(V) 125.00 VDC2(V) 48.00
=>>
Figure 3.29 Terminal Screen MET Metering Quantities
