Spectracom SecureSync User Manual

1.
Navigate to MANAGEMENT > NETWORK: NTP Setup.
2.
In the NTP Services panel, click the GEAR icon in the top-right corner.
3.
The Edit NTP Services window will display.
4.
Click the Autokey tab.
5.
Check the Autokey box.
6.
Fill in the Passphrase field by creating a passphrase (for a Trusted server—see Certificate
Type below), or by using the existing passphrase of your trusted server (for Server and
Client certificates).
7.
Select the Certificate Type for your server, by clicking the appropriate radio button for
Server, Client, or Trusted.
T R U S T E D S e r v e r :
Before a server can be designated Client or Server status, one server must be designated as
Trusted. When designating a server as Trusted:
1. Choose the Trusted radio button.
2. Click the Submit button.
A Groupkey is then generated for the network. This Groupkey will be pasted into the Group-
key box to designate another server on the network as Client or Server.
114
CHAPTER 2 • SecureSync User Reference Guide Rev. 26
2.14 Configuring NTP

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
