Spectracom SecureSync User Manual

*****************************************************
Example zebra.conf file showing the default file with no addresses configured:
(Interface eth0 line, with no lines following it because no addresses are configured on the port)
*****************************************************
!
interface eth0
!
interface lo
*****************************************************
Example ospfd.conf file:
*****************************************************!
router ospf
ospf router-id 10.2.100.157
network 10.2.0.0/16 area 0.0.0.0
redistribute connected
distribute-list default out connected
!
access-list default permit 10.10.14.1/32
access-list default deny any
*****************************************************
Example ospf6d.conf file:
*****************************************************
!
interface eth0
!
router ospf6
router-id 10.2.100.157
interface eth0 area 0.0.0.0
redistribute connected
!
*****************************************************
Example bgpd.conf file:
*****************************************************!
2.14 Configuring NTP
CHAPTER 2 • SecureSync User Reference Guide Rev. 26
129

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
