Function Web UI Name Illustration ID* Inputs Outputs Conn.'s
1in/3out 1PPS
(TTL [BNC])
1PPS/Frequency
RS-485
28
1PPS (1x) 1PPS (3x) BNC
(4x)
1in/2out
1PPS/freq
(fiber optic)
1PPS In/Out,
Fiber
2A
1PPS (1x) 1PPS (2) ST Fiber
optic
(3x)
5MHz out 5MHz Out
08
0 5MHz (3x) BNC
(3x)
10 MHz out 10 MHz Out
1C
0 10 MHz (3x) BNC
(3x)
10 MHz out 10 MHz Out
38
0 10 MHz (3x) TNC
(3x)
1MHz out 1MHz Out
26
0 1MHz (3x) BNC
(3x)
Progr. frequ.
out (Sine
Wave)
Prog Freq Out,
Sine
13
0 progr. clock,
sine (4x)
BNC
(4x)
Progr. frequ out
(TTL)
Prog Freq Out, TTL
2F
0 progr. clock,
TTL/sq. (4x)
BNC
(4x)
Prog frequ out
(RS-485)
Prog Freq Out, RS-
485
30
0 progr. clock,
RS-485 (4x)
Terminal
block,
10-pin
Square Wave
out
Square Wave
Out, BNC
17
0 square wave,
TTL (4x)
BNC
(4x)
1PPS in/out +
frequ. in
1PPS/Frequency
BNC
01
Var. frequ. +
1PPS
1PPS (TTL) BNC
(3x)
1PPS in/out +
frequ. in
1PPS/Frequency
RS-485
03
10 MHz +
1PPS
1PPS Terminal
block,
10-pin
CTCSS, Data
Sync/Clock
Simulcast
14
0 data clock,
CTCSS frequ.,
1PPS, 1alarm
(3x)
RJ-12 &
DB-9
Telecom Timing Cards
E1/T1 data,
75Ω
E1/T1 Out BNC
09
0 1.544/2.048
MHz (1x)
unbal. E1/T1
(2x)
BNC
(3x)
E1/T1 data,
100/120Ω
E1/T1 Out Ter-
minal
0A
0 1.544/2.048
MHz (1x)
unbal. E1/T1
(2x)
Terminal
block,
10-pin
1.5 Option Cards
