Function Web UI Name Illustration ID* Inputs Outputs Conn.'s
Time Code Cards
ASCII Time
Code RS-232
ASCII Timecode
RS-232
02
1 RS-232 (1x) DB-9
(2x)
ASCII Time
Code RS-485
ASCII Timecode
RS-485
04
1 1 Terminal
block,
10-pin
IRIG BNC IRIG In/Out BNC
05
1 2 BNC
(3x)
IRIG Fiber
Optic
IRIG In/Out, Fiber
27
1 2 ST Fiber
optic
(3x)
IRIG out, BNC IRIGOut BNC
15
0 4 BNC
(4x)
IRIG out, fiber
optic
IRIG Out, Fiber
1E
0 4 ST Fiber
optic
(4x)
IRIG out, RS-
485
IRIGOut, RS-485
22
0 4 Terminal
block,
10-pin
STANAG input STANAG In
1D
2x 1x DB-25
(1x)
STANAG in,
isol.
STANAG In, Isol-
ated
24
2x 1x DB-25
(1x)
STANAG out STANAG Out
11
0 2x STANAG,
1x 1PPS
DB-25
(1x)
STANAG out,
isol.
STANAG Out,
Isolated
25
0 2x STANAG,
1x 1PPS
DB-25
(1x)
HAVE QUICK
out BNC
HAVE QUICK
Out, BNC
10
0 4 (TTL) BNC
(4x)
HAVE QUICK
out RS-485
HAVE QUICK
Out, RS-485
1B
0 4 Terminal
block,
10-pin
HAVE QUICK HAVE QUICK
29
1 3 BNC
(4x)
Networking Cards
Gigabit Eth-
ernet
Gb Ethernet
06
(3, OR output) (3, OR input) RJ-45
(3x)
12
CHAPTER 1 • SecureSync User Reference Guide Rev. 26
1.5 Option Cards

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
