Spectracom SecureSync User Manual

d.
Locate and upload the certificate or client key file.
e.
Click Submit.
The SSL certificates and/or client key you upload will be installed in the /home/spec-
tracom/xfer/cert/ directory.
Use the checkbox Enable Security if you want to enable SSL security, i.e. use Secure LDAP.
Use the checkbox Clean Security Certificates to remove all certificates currently stored on
SecureSync (e.g., to eliminate expired certificates).
LDAP Group Settings
Under the LDAP Group tab, you can filter access by group.
To enable group authentication:
a.
Select the Enable group filter checkbox.
b.
Enter information for:
Required Group—Enter the required group. Example. : ou=Group,
dc=example, dc=com.
Group Attribute—Enter the group attribute. Example: member.
NSS base group—Enter the nss_base group. Example: ou=Group, dc=example,
dc=com?one.
c.
Click the Submit button.
LDAP Advanced Settings
4.3 Managing Users and Security
CHAPTER 4 • SecureSync User Reference Guide Rev. 26
259

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
