2.
The Status window will display a list of all outputs of the selected category:
To display more detailed information about a particular output, click the corresponding
INFO button.
To edit the settings of a given output, click the GEAR button (see also "Configuring Out-
puts" on page136.)
To refresh the information displayed, click the REFRESH button (circling arrows icon).
In the illustration of the rear panel, click on a connector to highlight the corresponding
list entry.
Displaying the settings of a specific output
The outputs installed in your SecureSync unit have specific settings that can be reviewed, and—
to some extent—edited.
To display the settings of an output:
1.
Navigate to INTERFACES > OUTPUTS, and click on the desired output (recessed e.g., PPS Out-
put 0):
286
CHAPTER 4 • SecureSync User Reference Guide Rev. 26
4.5 Quality Management
