Alarm Outputs: Edit Window
To configure one of the ALARM Outputs, go to its Edit window. For instructions, see: "Con-
figuring Option Card Inputs/Outputs" on page348.
The Web UI list entry for this card is named: Simulcast.
Note: Alarm Output 0 through Alarm Output 3 are reserved by SecureSync. Num-
bering for alarm outputs from the option card will begin at Alarm 4, which is
available on the DB-9 output, while Alarms 5 and 6 are assigned to the RJ-12 con-
nector.
Note: You can configure the alarm type (None, Minor, or Major) for both the DB-
9 and RJ-12 connectors. For additional information on alarm types, see "Minor
and Major Alarms" on page335.
The Edit window allows the configuration of the following settings:
Alarm Type:
None—Will not output for an alarm
Minor—Will output on a minor alarm
Major—Will output on a major alarm.
SecureSync User Reference Guide 401
