Spectracom SecureSync User Manual

J1 Pin No. Function
3 GND
4 IRIG Output 2 +
5 IRIG Output 2 –
6 IRIG Output 3 +
7 IRIG Output 3 –
8 GND
9 IRIG Output 4 +
10 IRIG Output 4 –
Table 5-16:
1204-22 terminal block pin-out
IRIG Output: Viewing Signal State
To quickly view if an IRIG output is enabled or disabled, go to the option card’s Status Sum-
mary panel. For instructions, see: "Viewing an Input/Output Signal State" on page349.
IRIG Output: Edit Window
To configure an IRIG Output, go to its Edit window. For instructions, see: "Configuring Option
Card Inputs/Outputs" on page348.
The Web UI list entries for these option cards are: IRIG Out BNC, IRIG Out Fiber, IRIG Out RS-
485.
Note: SecureSync starts numbering I/O ports with 0 (only 1PPS and 10MHz out-
puts start at1, because of the built-in outputs).
SecureSync User Reference Guide 411
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
